Leak Detection in Howe, TX — Find It Before You Open a Wall
A water bill that jumped 30% with no change in usage. A ceiling stain that keeps reappearing after patches. A soft spot in the flooring with no visible source. These are signs of a hidden leak that's been running long enough to cause structural damage — and every day it runs is money lost and damage accumulating. Masters Plumbing Service uses acoustic ground microphones, thermal imaging cameras, and precision pressure testing in Howe, TX to locate leaks without speculative demolition.
4 Detection Capabilities We Bring to Every Leak Detection Call
A pressure test tells us a leak exists and how much water is escaping. Detection equipment tells us precisely where.
🎙️
Acoustic Ground Microphone
Acoustic detection is most effective on metal pipe (copper, cast iron) under slab or in concrete — materials that conduct sound efficiently. It works in quiet environments and requires shutting off the house briefly to establish a clean acoustic baseline.
🌡️
Infrared Thermal Camera
Thermal imaging is particularly effective inside insulated wall cavities and for finding the extent of moisture spread beyond the immediate leak point. It tells us not just where the pipe is failing but how far the moisture has already traveled.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
Tracer gas detection is the method of last resort for the most challenging cases — it adds cost and setup time. We use it when acoustic and thermal methods haven't produced a definitive location and the evidence clearly supports an active leak.
What We Locate
Leak Detection for Walls, Slabs, Pools & Irrigation in Howe
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
We document the thermal anomaly, mark the approximate pipe location, and recommend a minimal access cut rather than a wide wall opening.
Water Main
Underground Supply Line Detection
We mark the ground above the detected leak location so the repair crew opens only the section they need to.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Pool plumbing — suction and return lines buried between the equipment pad and the pool shell — can develop leaks at fittings or in the pipe body that appear as unexplained water loss. We pressure-test the pool plumbing circuit, isolate the return and suction lines separately, and use acoustic detection to find which line and where.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
Insurance claims for water damage from hidden leaks typically require documentation that the leak was not visible or detectable without specialized equipment. Our detection report includes: pressure test results confirming active water loss, detection method used, thermal imagery or acoustic mapping showing leak location, and technician certification information.
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
We start at the meter. All fixtures off, we watch the meter for 10 minutes. Movement confirms active water loss from the supply side. We also check for any visible evidence — water stains, soft floors, moisture readings with a moisture meter at suspect wall surfaces.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
We document findings with thermal images and note detection readings at multiple grid points to triangulate the strongest signal.
4
Written Report & Repair Options
You receive a written detection report including pressure test results, detection method summary, leak location (described relative to fixed reference points), and thermal imagery. If you want us to repair the leak, we quote the repair and execute immediately. If you have your own plumber, the report gives them everything they need.
Customer Reviews
Real Leak Detection Reviews from Howe
★★★★★
My water bill doubled over three months with no change in usage. Masters Plumbing Service came out, confirmed the meter was moving with everything off, isolated the cold supply to the kitchen as the failing branch, and used the acoustic device on the slab to pinpoint a location 4 feet from the outside wall under the kitchen floor. The repair crew opened a 10-inch circle in the tile, found a pinhole in a copper elbow exactly where detection said it would be. I was skeptical acoustic detection was that precise — it was.
— C. Thornton, Howe
★★★★★
Our insurance company required professional leak detection documentation before approving the claim. Masters Plumbing Service's written report with pressure test data and thermal imagery was exactly what the adjuster needed. Claim approved. The detection cost was covered as part of the claim.
— B. Osei, Howe, TX
★★★★★
Pool was losing 2 inches of water per day — more than evaporation could explain. Masters Plumbing Service pressure-tested the plumbing circuit, isolated the issue to the return line, and ran acoustic detection along the line path to find the failure at a union fitting under the decking. Repair required pulling one deck board instead of the exploratory digging another company had proposed. Excellent, focused work.
— T. Anand, Howe, TX
Common Questions
Leak Detection Questions We Answer in Howe
The most reliable self-check: shut off every fixture and appliance in the house, then watch the water meter for 15 minutes. Any movement — including the small leak indicator dial — means water is escaping the supply side somewhere. If the main meter dial moves with everything off, you have a leak. Call us to locate it.
In most cases, yes — the detection phase is entirely non-invasive. We locate the leak using acoustic, thermal, and pressure methods without any demolition. The detection tells us exactly where to open, which means the access opening is minimal rather than speculative.
For pressurized supply lines in concrete or metal pipe, acoustic detection is typically accurate to within 6–18 inches under ideal conditions — quiet environment, no interference from other water use, metal pipe conducting sound clearly. Thermal imaging is accurate to the size of the wet zone it reveals, which varies based on how long the leak has been running and how far moisture has migrated.
Yes. Our written detection report includes: technician credentials, equipment identification, pressure test methodology and results, detection method description, leak location with reference measurements, and supporting thermal imagery. This is the documentation format most insurance adjusters require to approve a concealed-leak water damage claim.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
The repair quote is given before any wall or floor is opened. You know the full cost of detection + repair before anything is cut.
Service Area
Masters Plumbing Service Detection Technicians in Howe and Beyond
Our detection technicians are equipped with acoustic, thermal, and tracer gas tools for the full range of leak scenarios found in Howe, TX homes and commercial properties.
